IRISMO 45 WIREFREE RTS - 1002353 - 1 - Somfy

Ref : 1002353 - IRISMO WIREFREE 45 RTS EU W/BAT

IRISMO 45 WIREFREE RTS

IRISMO 45 WIREFREE RTS

More about
Application
Curtains
Technology
RTS technology

Product benefits

Reliable, robust and discreet

  • The premium solution for residential markets
  • Curtain weight up to 45kg

Easy Installation

  • Motor is battery operated, no wiring required
  • No need to have electrical knowledge
  • Motor can be installed on the right or left side of the track

Convenience

  • The removable battery is compact and easy to recharge

Details and specifications

Irismo 45 WireFree RTS is completely battery operated, lifting one of the biggest burdens for end users - wiring. With quick and clean installation, no more visible wiring, and no damage to walls, Irismo 45 WireFree RTS is the ideal solution for every project to display prestigious aesthetic details.

As a low consumption battery motor the battery life lasts up to 9 months. It is compatible with RTS allowing users to enjoy their smart home by controlling curtains with Connexoon Window RTS and voice control (through IFTTT).

Key Features

  • Touch Motion feature which is perfect for every situation
  • Battery-operated, no more visible wiring or damage to walls
  • Low consumption, only needs to be charged once every nine months
  • Provides the level of comfort and reliability expected in luxury locations
  • Improves the image of a venue with elegance and makes the job of service personnel easier

Other documents & links

Others

Technical information

End product
Weight 45
End product type Curtains

Technology
Radio Frequency 433.42   MHz

Electrical
Minimum voltage 24   V
Maximum Voltage 24   V
Nominal Voltage / Frequency Battery Pack

Mechanical
Nominal Torque 0.8   Nm
Nominal Speed 87.5   rpm
Type of limit switch unit Adjustable limits

Standard
Insulation class I
Protection Index IP30

Cable
Color white

Dimension
Rail length 10   m

Other
Noise level (according to Somfy measures) 41   dBA
Information To retain the motor’s battery lifespan, Somfy recommends recharging the battery at least once every 12 months, even if power remains. If the battery goes flat, recharge it immediately. Leaving a battery fully discharged for more than two months may irreparably damage its ability to recharge.
Working temperature 0-60   °C
