SONESSE 50 ILT2 3/28 3M White Cable - 1030051 - 1 - Somfy

Ref : 1030051 - SONESSE 50 ILT2 3/28 VVF 3M - UNIT

SONESSE 50 ILT2 3/28 3M White Cable

SONESSE 50 ILT2 3/28 3M White Cable

Application
Interior blinds
Technology
Wired Technology (WT)

Details and specifications

  • 230V / 50Hz tubular motor.
  • The Sonesse 50 has been adapted to be an ultra quiet rollerblind motor.
  • Standard star head configuration
  • Modular control options – IR, RTS or Dry Contact
  • Tool operated limit setting.
  • 300 turn limit capacity.
  • Suitable for tubes: Ø50 to Ø65.
  • Volt free switch control via flat 4 core telephone data cable
  • Requires the use of a crown and wheel for tube adaptation.
  • Horizontal mount only.
  • Intermittent usage.

Technical information

Electrical
Nominal Voltage / Frequency 230V - 50Hz
Maximum Voltage 253   V
Minimum voltage 207   V
Consumption during operation 90   W

Mechanical
Nominal Torque 3   Nm
Nominal Speed 28   rpm
Type of limit switch unit Electronic
Capacity of the limit switch unit 300   turns
Repeatabilty <± 2   °

Standard
Protection Index IP 31

Cable
Wire Length 3   m
Number of wires of the cable 3
Color White
Cable type VVF
Wire section 0,75   mm²

Dimension
Weight 2,875   Kg
Riveting position distance (L2) 770   mm
Overall length (L3) 783   mm
Length (L1) 796   mm
Basic crown for tube diameter 50 x 1,5   mm

Other
Noise level (according to Somfy measures) 44   dBA
Working temperature 0 to + 60   °C
Thermal time <=4   mn

Last consulted articles

SMOOVE 1 PURE RTS
Réf. 1810881
SITUO 5 SOLIRIS RTS PURE
