JET 10/17 RH 2.5M White Cable - 1037351 - 1 - Somfy

Ref : 1037351 - LT JET 10/17 RH VVF 2,5M - UNIT

JET 10/17 RH 2.5M White Cable

JET 10/17 RH 2.5M White Cable

Application
Roller shutters,Interior blinds,External Screens
Technology
Wired Technology (WT)

Details and specifications

Programming Instructions for all our products can be found in the Somfy Pocket Book.  You will need to log in to the Somfy Professionals website for access

Other documents & links

Others

Technical information

Electrical
Consumption during operation 120   W
Minimum voltage 207   V
Maximum Voltage 244   V
Rated current 0.5   A
Nominal Voltage / Frequency 230V - 50Hz

Mechanical
Capacity of the limit switch unit 46   turns
Type of limit switch unit Quick limit switch
Type of head Round head
Nominal Speed 17   rpm
Nominal Torque 10   Nm
Repeatabilty ± 5   °

Standard
Approval RCM
Protection Index IP 44
Insulation class Class I

Cable
Plug in cable Black LT Plug
Cable type PVC
Wire section 0,75   mm²
Color White
Wire Length 2,5   m
Number of wires of the cable 4

Dimension
Riveting position distance (L2) 510   mm
Weight 1,85   Kg
Overall length (L3) 525   mm
Basic crown for tube diameter 50 x 1,5   mm
Length (L1) 530   mm

Other
Thermal time 4   mn
Noise level (according to Somfy measures) 47   dBA
Working temperature -10 to +40   °C
