OREA 60 RTS 55/17 3M White Cable - 1181068 - 1 - Somfy

Ref : 1181068 - OREA 60 RTS 55/17 VVF 3M - UNIT

OREA 60 RTS 55/17 3M White Cable

OREA 60 RTS 55/17 3M White Cable

Application
Awnings
Technology
RTS technology

Details and specifications

Programming Instructions for all our products can be found in the Somfy Pocket Book.  You will need to log in to the Somfy Professionals website for access

Other documents & links

Others

Technical information

Technology
Radio Frequency 433,42   MHz
Capacity of memory 12 different transmitters plus 3 wireless sensors
Coding Rolling code 16 million of possibilities
Range in house 20m through 2 reinforced concrete walls

Electrical
Antenna Integrated
Consumption during operation 320   W
Minimum voltage 207   V
Maximum Voltage 253   V
Rated current 1.25   A
Nominal Voltage / Frequency 230V 50Hz

Mechanical
Capacity of the limit switch unit 200   turns
Type of limit switch unit Electronic
Type of head Star head
Nominal Speed 17   rpm
Nominal Torque 55   Nm
Repeatabilty <± 3   °

Standard
Approval RCM
Protection Index IP44
Insulation class Class I

Cable
Plug in cable Grey LT Plug
Cable type PVC
Wire section 0.75   mm²
Color White
Wire Length 3   m
Number of wires of the cable 3

Dimension
Riveting position distance (L2) 717   mm
Weight 4.39   Kg
Overall length (L3) 734   mm
Basic crown for tube diameter 63 x 1,5   mm
Length (L1) 740   mm

Other
Thermal time 4   mn
Noise level (according to Somfy measures) 64   dBA
Working temperature -10 to +40   °C
