Ref : 1247151 - MOVELITE 60 RTS 1.0M WHITE CABLE W/ ILC WHITE
MOVELITE 60 RTS 1.0M WHITE CABLE W/ ILC WHITE
An accessible and elegant curtain motorisation solution with the essential features
| Application | ||
|---|---|---|
| Curtains | ||
| Technology | Warranty | |
| RTS technology | 5 Years | |
Product benefits
Reliable and minimalistic
• A curtain motor solution with the essential functions
• Suitable for residential and commercial projects
Adaptive and effective
• Compatible with multiple technologies (WT/RTS/DCT*) to meet varying needs and applications
• Curtain weight up to 35kg
Installation Versatility
• Also available with open cable [1246077]
Technical information
Technology |
|
|---|---|
| Radio Frequency | 433.42 MHz |
| Range in open field | 200m |
| Range in house | 20m |
Electrical |
|
|---|---|
| Antenna | Integrated |
| Consumption in standby mode | 0.49 W |
| Minimum voltage | 100 V |
| Nominal Voltage / Frequency | AC - RGE 1 - 230V/50HZ |
Mechanical |
|
|---|---|
| Nominal Speed | 15cm/s - 105 rpm |
| Nominal Torque | 1 Nm |
Standard |
|
|---|---|
| Approval | RCM |
| Protection Index | IP30 |
| Insulation class | Class I |
Cable |
|
|---|---|
| Plug in cable | IN-LINE CONNECTOR |
| Cable type | VVF |
| Wire section | 0.75 mm² |
| Color | WHITE |
| Wire Length | 1 m |
| Number of wires of the cable | 4 |
Dimension |
|
|---|---|
| Overall length (L3) | 283 mm |
| Length (L1) | 283 mm |
| Rail length | 10 m |
Other |
|
|---|---|
| Working temperature | 0°C to +60 °C |
