CHRONIS UNO
Ref : 1805007 - CHRONIS UNO
CHRONIS UNO
CHRONIS UNO
| Application | ||
|---|---|---|
| Interior blinds,External Screens,Roller shutters,Awnings | ||
| Technology | Warranty | |
| Wired Technology (WT) | 3 Years | |
Product benefits
Details and specifications
- 230V AC controller for a single motor with timer function and manual operation.
- Configurable one up, one down time per day that can differ each day of the week.
-
Programming Instructions for all our products can be found in the Somfy Pocket Book. You will need to log in to the Somfy Professionals website for access.
Technical information
Electrical |
|
|---|---|
| Output type of contact | 230V 3A cosφ 0,8 |
| Minimum voltage | 207 V |
| Maximum Voltage | 253 V |
| Nominal Voltage / Frequency | 230V 50/60Hz |
Standard |
|
|---|---|
| Insulation class | Class II |
| Protection Index | IP40 |
| Approval | RCM |
Cable |
|
|---|---|
| Wire section | 0.75 - 1.5 mm² |
Dimension |
|
|---|---|
| Width | 80 mm |
| Height | 80 mm |
| Depth | 50 mm |
Other |
|
|---|---|
| Working temperature | +5 to +40 °C |
| Color / Finish | White on grey |
