DC RTS RECEIVER - 1870139 - 1 - Somfy

Ref : 1870139 - DC RTS RECEIVER - EN EL AR RU

DC RTS RECEIVER

DC RTS RECEIVER

Application
Interior blinds
Technology
RTS technology

Details and specifications

  • Radio receiver for 24V DC WT motors. Allows for the use of an RTS transmitter. Compatible only with standard 24V WT motors, a suitable power supply is also required. Rolling code.
  • Maximum number of motors: 2x LV25-B44/ LW25-B44.
    2x LV25-B64.
    2x LT 28.
    2x LW25-B83.
    1x Linkeo 2.
    1x Rodeo.
  • Programming Instructions for all our products can be found in the Somfy Pocket Book. You will need to log in to the Somfy Professionals website for access.

Other documents & links

Others

Technical information

Technology

Range in open field 200
Range in house 20
Radio Frequency 433.42   MHz

Electrical

Minimum voltage 20.5   V
Maximum Voltage 27   V
Nominal Voltage / Frequency 24 VDC
Rated current 1.3   A

Standard

Insulation class III
Protection Index IP 20
Approval RCM

Cable

Wire section 1.5   mm²

Dimension

Width 150   mm
Height 25   mm
Weight 0.030   Kg
Depth 25   mm

Other

Working temperature -10 to +60   °C
Information For indoor use only
