- Obsolete product
POWER 1X2.5DC RTS
Ref : 1870158 - POWER 1X2.5DCRTS SVFIENODARU
POWER 1X2.5DC RTS
POWER 1X2.5DC RTS
| Application | ||
|---|---|---|
| Interior blinds | ||
| Technology | ||
| RTS technology | ||
Details and specifications
- RTS receiver with integrated 24V DC power supply.
- Possibility to drive up to 6 DC 24V actuators.
- Compatible with LV25/LW25 and LT28.
- Compatible with all RTS control, including Modulis remote control, Sunis sun sensor and Impressario control.
- Programming Instructions for all our products can be found in the Somfy Pocket Book. You will need to log in to the Somfy Professionals website for access.
Technical information
Technology |
|
|---|---|
| Range in open field | 200 |
| Range in house | 20 |
| Radio Frequency | 433.42 MHz |
| Bus type | RTS |
Electrical |
|
|---|---|
| Maximum accessory current | 2.5 |
| Output type of contact | 24Vdc SELV regulated |
| Consumption in standby mode | 0.7 W |
| Minimum voltage | 198 V |
| Maximum Voltage | 255 V |
| Nominal Voltage / Frequency | 230V 50Hz |
Standard |
|
|---|---|
| Insulation class | II |
| Protection Index | IP 20 |
| Approval | RCM |
Cable |
|
|---|---|
| Wire section | 1.5 mm² |
Dimension |
|
|---|---|
| Width | 155 mm |
| Height | 155 mm |
| Weight | 0.450 Kg |
| Depth | 54 mm |
Other |
|
|---|---|
| Working temperature | -10 to +55 °C |
| Color / Finish | White |
| Information | For indoor use only |
