Ref : 9704138 - RIGHT LS40 ABS WHEEL
Ø40mm obstacle detection motor solution suitable for Fabric Zip Systems
| Application | ||
|---|---|---|
| Roller shutters,External Screens |
Product benefits
Compatible with RTS or RS485 40mm motors. Obstacle detection gives an added peace of mind by preventing damage to a Fabric Zip system.
Guidelines & Considerations
- The Ø40mm ABS wheels are only compatible with RTS and RS485 technology
-
The Ø40mm motor must have electronic limit switches
-
For all applications with a Ø40mm ABS wheel; side channels [with a fabric trap via zip] as well as a headbox is mandatory
-
Installers must carefully select either a Right hand or a Left hand Ø40mm ABS wheels using the selection guide in Ø40mm Technical Datasheet
-
The minimum Torque to engage the free wheel is 0.2Nm
-
The Ø40mm ABS wheels adds up to 20mm extra length when fixed to the drive wheel
-
Compatible with a maximum torque of 13Nm
