Electrical
Consumption during operation	90   W
Minimum voltage	207   V
Maximum Voltage	244   V
Rated current	0.4   A
Nominal Voltage / Frequency	230V - 50Hz

Mechanical
Capacity of the limit switch unit	46   turns
Type of limit switch unit	Quick limit switch
Type of head	Round head
Nominal Speed	17   rpm
Nominal Torque	6   Nm
Repeatabilty	± 5   °

Standard
Approval	RCM
Protection Index	IP 44
Insulation class	Class I

Cable
Plug in cable	Black LT Plug
Cable type	PVC
Wire section	0.75   mm²
Color	White
Wire Length	2.5   m
Number of wires of the cable	4

Dimension
Riveting position distance (L2)	490   mm
Weight	1.72   Kg
Overall length (L3)	505   mm
Basic crown for tube diameter	50 x 1.5   mm
Length (L1)	510   mm

Other
Thermal time	4   mn
Noise level (according to Somfy measures)	46   dBA
Working temperature	-10 to +40   °C
