MARINER 40/12 CSI RTS 2.5M White Cable - 1049037 - 1 - Somfy

Ref : 1049037 - MARINER 40/12 CSI RTS VVF 2,5M - UNIT

MARINER 40/12 CSI RTS 2.5M White Cable

MARINER 40/12 CSI RTS 2.5M White Cable

Application
Roller shutters,Awnings
Technology
RTS technology

Details and specifications

Programming Instructions for all our products can be found in the Somfy Pocket Book.  You will need to log in to the Somfy Professionals website for access

Other documents & links

Others

Technical information

Technology
Radio Frequency 433,42   MHz
Capacity of memory 12 different codes
Coding Rolling code 16 million of possibilities
Range in house 20 m with 2 reinforced concrete walls to be passed through

Electrical
Antenna Integrated antenna
Consumption during operation 240   W
Minimum voltage 207   V
Maximum Voltage 244   V
Nominal Voltage / Frequency 230V - 50Hz
Rated current 1.1   A

Mechanical
Nominal Torque 40   Nm
Nominal Speed 12   rpm
Repeatabilty ± 5   °
Capacity of the limit switch unit 34   turns
Type of limit switch unit Quick limit switch

Standard
Approval RCM
Insulation class Class I
Protection Index IP 44

Cable
Number of wires of the cable 3
Wire section 0,75   mm²
Plug in cable LT CSI RTS Plug
Cable type PVC
Color White
Wire Length 2,5   m

Dimension
Overall length (L3) 774   mm
Riveting position distance (L2) 759   mm
Weight 3,21   Kg
Length (L1) 787   mm
Basic crown for tube diameter 50 x 1,5   mm

Other
Noise level (according to Somfy measures) 55   dBA
Thermal time 4   mn
Working temperature -10 to +40   °C
