Ref : 1117161 - OREA 50 WT 40/17 VVF 3M - BAR

OREA 50 WT 40/17 3M White Cable

Application
Awnings,External Screens
Technology
Wired Technology (WT)

Details and specifications

Description

Limits must be set using a Universal Test Lead (9015971).

Programming Instructions for all our products can be found in the Somfy Pocket Book. You will need to log in to the Somfy Professionals website for access

Technical information

Electrical
Consumption during operation	270 W
Minimum voltage	207 V
Maximum Voltage	253 V
Rated current	1.1 A
Nominal Voltage / Frequency	230V 50Hz

Mechanical
Capacity of the limit switch unit	250 turns
Type of limit switch unit	Electronic
Type of head	Star head
Nominal Speed	17 rpm
Nominal Torque	40 Nm
Repeatabilty	<± 4 °

Standard
Approval	RCM
Protection Index	IP44
Insulation class	Class I

Cable
Plug in cable	Black LT Plug
Cable type	PVC
Wire section	0.75 mm²
Color	White
Wire Length	3 m
Number of wires of the cable	4

Dimension
Riveting position distance (L2)	640 mm
Weight	2.8 Kg
Diameter	50 mm
Overall length (L3)	663 mm
Basic crown for tube diameter	50 x 1.5 mm
Length (L1)	655 mm

Other
Installation	To be installed in a tube mounted horizontally
Thermal time	4 mn
Noise level (according to Somfy measures)	57 dBA
Working temperature	-10 to +40 °C
