Ref : 1247537 - SONESSE 40 WTe 6/20 WITH INLINE CONNECTOR

SONESSE 40 WTe 6/20 WITH INLINE CONNECTOR

The whisper quiet, 40mm wired (WT) motor with electronic limits switches.

Product benefits

BENEFITS FOR PROFESSIONALS

Wired motor with electronic limit smitches allows for quick and easy comissioning and adjustment (requires universal test lead: 9027064 – sold separately)
Set motor from the ground (no need to access the motor head)
Parallel wire up to 4 motors to 1 switch (Group control)
Available in a range of torques (3, 6, 9Nm)
Quiet, smooth operation
Works with a wide range of interior applications
Inline connector option available for ease of programming & pre-wiring
Compatible with existing 40mm crown & drive accessories
Suitable for tube diameter 37mm or more (internal diameter)

BENEFITS FOR END USERS

INSTALLATION CONSIDERATIONS:

A [9027064] Universal test lead (sold separately) is required to set limits, adjust limits or reset motor settings.
An in-line connector cable must be installed by a qualified electrician in accordance with industry standard AS/NZS3000.
You must turn off power to this cable before you connect or disconnect this motor.
Power may only be supplied to this cable once male & female connectors are correctly coupled.
Failure to do so could compromise personal safety.
In-line connector for indoor use only.
When installing the in-line connector to comply with AS/NZS 60335:1:2020 you must order & use an in-line connector housing ref.9015865. Installation/use of an exposed in-line connector is a safety risk.

End product
End product type	Roller Blinds, Roman Blinds, Pleated Blinds, Zebra & Sheer

Electrical
Rated current	0.45 A
Nominal Voltage / Frequency	240V AC - 50HZ

Dimension
Diameter	40 mm
Overall length (L3)	535 mm

Other
Information	A [9027064] Universal test lead (sold separately) is required to set limits, adjust limits or reset motor settings.
Thermal time	4 mn
Noise level (according to Somfy measures)	45 dBA
Working temperature	0°C - 60°C °C
